Operation class
Class D
Number of Channels
01
Maximum power
@ 12,6 VDC - 1 OHM: 1200W RMS @ 12,6 VDC - 2 OHMS: 675W RMS @ 12,6 VDC - 4 OHMS: 370W RMS
Input Sensitivity
18K OHMS
Signal to Noise Ratio
>90dB
Frequency response
10Hz to 20KHz
Crossover high pass (HPF)
10Hz ~ 80Hz (-12dB/8ª) Variable
Crossover low pass (LPF)
80Hz ~ Full (-12dB/8ª) Variable
Bass Boost
0 ~ 10dB Variable Frequency (35 ~ 55)
Thermal Management
(PT) Smart Cooler com 2 velocidades
Efficiency
79%
Input Impedance
10k OHMS
Output Impedance
1 OHM
Protection system
Output Short / High and Low Power Supply
Min. Supply Voltage
9 VDC
Maximum Power Supply Voltage
16 VDC
Consumption at rest
900mA
Maximum music consumption
@ 12,6 VDC: 60A
Maximum consumption in sinusoidal signal
@ 12,6VDC: 120A
Dimensions (H x W x D) mm
184 x 54 x 177mm
Weight
1,395Kg
