Operation class
(PT) D
Number of Channels
(PT) 3
Maximum power
(PT) @ 12,6 VDC: 800W RMS CH1/CH2 (2 x 200W RMS) 1OHM, CH3 (1 x 400W RMS) 2OHMS
Input Sensitivity
(PT) 250mV
Signal to Noise Ratio
(PT) >88dB
Frequency response
(PT) CH1/CH2 100Hz ~ 25KHz 10Hz ~ 100Hz (LPF = 100Hz) CH3 10Hz ~ 700Hz (LPF = 700Hz) 10Hz ~ 25KHz (LPF = OFF)
Crossover high pass (HPF)
(PT) (CH1 / CH2) 100Hz (-12dB/8ª) Fixo
Crossover low pass (LPF)
(PT) (CH3) 100Hz, 700Hz, OFF (-12dB/8ª) Selecionável
Input Impedance
(PT) 10K OHMS (RCA) e 1K OHMS (FIO)
Protection system
(PT) Sobrecarga na saída
Min. Supply Voltage
(PT) 9 VDC
Maximum Power Supply Voltage
(PT) 16 VDC
Consumption at rest
(PT) 1,0A
Maximum music consumption
(PT) 51A
Maximum consumption in sinusoidal signal
(PT) 102A
Dimensions (H x W x D) mm
(PT) 173 x 52 x 227mm
Weight
(PT) 1,43Kg
