Technical information
Operation class
Class D
Number of Channels
02
Maximum power
@ 12.6 VDC - 2 Ohms: 250 Watts RMS (2 x 125W RMS) @ 12.6 VDC - 4 Ohms: 158 Watts RMS (2 x 79W RMS) 1 bridgeable channel - @12.6 VDC - 4 Ohms: 250W RMS (1 x 250W RMS)
Input Sensitivity
250mV a 6V
Signal to Noise Ratio
>88dB
Frequency Response
8Hz ~ 35KHz (-3dB)
Crossover high pass (HPF)
80Hz ~ 2.2KHz (-6dB/8th) Variable
Crossover low pass (LPF)
80Hz (-12dB/8th) Fixed
Input Impedance
10K Ohms
Output Impedance
2 Ohms
protection system
Output short circuit
Min. Supply Voltage
9 VDC
Maximum Power Supply Voltage
16 VDC
Consumption at rest
0.63A
Maximum music consumption
@12.6 VDC: 15A
Maximum consumption in sinusoidal signal
30A
Dimensions (WxHxD)
138 x 49 x 121mm
Weight
0,46kg
EAN
7898556844567
