Operation class
Class D
Number of Channels
01
Maximum power
@ 12,6 VDC - 1 OHM: 1800W RMS @ 12,6 VDC - 2 OHMS: 1410W RMS
Input Sensitivity
220 mV
Signal to Noise Ratio
>88dB
Frequency response
10Hz ~ 20KHz (-3dB)
Crossover high pass (HPF)
10Hz ~ 80Hz (-12dB/8ª) Variable
Crossover low pass (LPF)
80Hz ~Full (-12dB/8ª) Variable
Bass Boost
0 ~ 10.5dB (50Hz)
Thermal Management
Smart Cooler (fan controlled by temperature or audio, with 3 speeds)
Efficiency
78%
Input Impedance
10k OHMS
Output Impedance
1 OHM
Protection system
Output Short / High/Low Supply Voltage / Thermal Protection
Min. Supply Voltage
9VDC
Maximum Power Supply Voltage
16VDC
Consumption at rest
1.7 A
Maximum music consumption
91 A
Maximum consumption in sinusoidal signal
182 A
Dimensions (H x W x D) mm
228 x 70 x 188mm
Weight
2.18Kg
